Wadim Plast COOLTHERM
Single-zone stationary cooler
• temperature control of injection moulds,
• cooling of blow moulds
• cooling of precise processes, e.g., in the pharmaceutical industry
files to download
01 Three models
- Cooling capacity: 4.8, 14.0, 18.2kW for conditions: set point 15°C at cooling medium temperature of 40°C
- Heating power 6 kW
- Compact cabinet on castors, powder-coated galvanised sheet metal, removable panels, easy access
- Uniform external dimensions regardless of cooling capacity: 1.1×0.46×1.1m (LxWxH)
- Hydraulic connections: 1 inch
- Light and sound alarm as standard
- Temperature and pressure sensors in the controlled cooling system
02 Features
High performance
• Process pump with 3 bar pressure and high flow (turbulent)
• Direct cooling (no indirect exchangers)
High quality
• Stainless steel exchangers (condenser and evaporator)
• Pressure tank protected against corrosion
• Main and auxiliary pumps in stainless steel casing
• Iron-free hydraulic components (stainless steel, brass, bronze, EPDM rubber)
• Precision 3-way valve
Flexibility and precision
• Water or ethylene glycol
• Automatic filling
• Wide temperature control range 5 to 90°C
• Control precision +- 0.5°C
Areas of application
• Temperature control of injection moulds (including cycle shortening)
• Cooling of blow moulds
• Cooling of precise processes, e.g., in the pharmaceutical or beer brewing industry
Cooling system
• Efficient hermetic reciprocating or scroll compressor
• Environmentally friendly refrigerant gas R 407 C
Requirements
• Power supply 3-phase, 400 V, 50 Hz.
• Cooling medium (water or ethylene glycol) with pressure min. 2 bar and maximum temperature of 40°C
Control panel
• Water or ethylene glycol
• Automatic filling
• Wide temperature control range 5 to 90°C
• Control precision +- 0.5°C
Energy efficiency
• Three operating modes automatically selected by the controller:
– cooling
– heating
– freecooling (cheap cooling)
• Direct cooling (with no intermediate exchangers)
